Technical Manual – Push Button Smart 55/63
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
27
27
Color of message text
any color
[red]
Setting of the color for the
message text
Indicate a message via
LEDs
▪ not active
▪ active
Setting if the LEDs should flash
at an active message
Color of LEDs
any color
[red]
Select the colour in which the
LEDs display the message
Only visible if " Indicate a
message via LEDs" is activated
Table 14: Settings – Messages
The message behavior depends on the parameter "Standby display at day / night". The different
behaviors are shown below:
Standby display
Incoming message during standby
no Standby
▪ No message is displayed but saved
Standby in upper
keypad
▪ Message is displayed on upper button pair and the upper LEDs
change between parameterized color and black at 600ms pulse
▪ At the same time, the parameterized color is set to double
brightness in order to increase the signal effect
▪ The message is only acknowledged by pressing to one of the
upper buttons.
▪ A keystroke on the middle and lower buttons performs the
displayed switching functions
Standby on full screen
▪ Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
▪ At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
▪ The message is acknowledged by pressing to any key
Display off
▪ No message is displayed during standby but saved.
▪ The message with the highest priority is indicated by the
keystroke after standby
▪ The displayed messages are acknowledged by means of further
key strokes
▪ Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
▪ At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
Display off and
orientation-LED on
▪ Message is displayed in the middle of the screen and all LEDs
change between parameterized color and black
▪ At the same time, the parameterized color is set to double
brightness in order to increase the signal effect.
▪ After the "timeout for standby", the LEDs will stop flashing and
the message disappears.
▪ If any button is pressed after the LEDs have stopped flashing, the
message with the highest priority is displayed again. Further
keystrokes acknowledge the messages
Table 15: Behavior of the device to an incoming message during standby
