MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
38 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.3.5 Subfunction: Multitouch-function
Single-button function
The “Multitouch-function” can send a xed value according to the set datapoint type, depending on how
often the button is pressed.
Note: A fast reaction time on keypress is recommended for the Multitouch-function.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Output objects ■ common object/DPT
■ different objects/DPT
Setting whether to send to one or
more objects.
Number of
tip-operations
■ 2
■ 3
Settings for the number of possible
tip functions.
Datapoint type
Datapoint type:
tip once
■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
The following options are available:
■ “Datapoint type” if common
object
■ “Datapoint type: tip once/
twice/triple” if different objects
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for“RGB value“.
Value tip once
Scene number tip
once
any value
according to set datapoint type
Setting the value/scene number to
be sent.
The settings for 2 or 3 touch operations behave in the same way
3./4. function
(long Keypress)
■ not active
■ active
Setting an additional function by
“long button”.
Datapoint type for
long keypress
■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Only if “3./4. function (long
keypress)” → “active”.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
