Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Button 1 - 4 ■ pressed = ON
■ pressed = OFF
Setting the value that is sent if the key is
pressed.
Only if “Internal input 1 or 2” →
“active”.
Button selection ■ not active
■ button 1 - 4
Select the button that sends.
Only if “Logic basic setting“ → “Setting
Logic 1“ → “send value on button
activation“.
The settings for the submenu Logic 2 - 4 correspond to those of submenu Logic 1
Table 47: Settings – Submenu: Logic 1 - 4
External inputs
Up to two external logic objects can be activated for the logic operations “AND” and “OR”. The default
setting species the value of the external logic object after a bus power return if no value has been
received yet.
Internal inputs
Up to two buttons can be dened as ‘internal inputs’, whereby the respective value that the pressed button
sends is specied. To use this function, the buttons must be activated under “Button functions”
(4.2 Button functions – General).
Send value on button activation
This function can be used to send a second value when a button is pressed, in addition to the normal
switch function. The value is determined under “Logic basic settings” (4.5.1 Logic basic settings). The
button that is to send the value is selected via the “Button selection”.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
50 Logic 1 – Input A 1 Bit External input for the logic operation
51 Logic 1 – Input B 1 Bit External input for the logic operation
+3 next Logic – Input
Table 48: Communication objects – Logic: Input objects
