Je bekijkt pagina 48 van 63
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
48 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.4 Status LED
Push Button Lite 55/63
Depending on the device and its conguration, up to 4 status LEDs can be congured. One LED can be
congured for each function, which is then labelled with LED1 - 4 in the parameters.
4.4.1 LED basic setting
Push Button Lite 55/63
The LED basic settings affect all active status LEDs.
The following table shows all available settings:
ETS Text
Dynamic range
[Default value]
Comment
LED colour on button
activation, only with
setting “Object and
button activation”
[off], red, green, yellow, blue, pink, cyan,
white
Setting the colour.
The parameter only works if the “object
and button activation” parameter is
selected in the relevant LED menu
under “LED reacts to:”.
Lock object for LEDs ■ not active
■ active
Activates a lock object which can lock
(switch-off) all LEDs.
Behaviour of LEDs on
bus power return
■ do not request LED objects
■ request LED objects
Setting whether the objects are
requested after a reset.
Works only when “LED reacts for:“ →
“external Object “.
Synchronization
object for flashing
LEDs
■ not active
■ active as master
■ active as slave
This synchronises the flashing of
several buttons on different devices.
Global brightness for
LEDs “Day”
■ not active
■ level 1 - 5
■ dynamic
[level 3]
Setting the brightness of the LEDs if the
system is in day mode.
Global brightness for
LEDs “Night”
■ not active
■ level 1 - 5
■ dynamic
[level 1]
Setting the brightness of the LEDs if the
system is in night mode.
Only if “Global brightness ...“ → “dynamic“.
Datapoint type for
dynamic brightness
■ 2 Byte DPT 9.004
Ambient Brightness (Lux)
■ 1 Byte DPT 5.001
Percent (0…100%)
Setting the DPT for brightness control.
