Je bekijkt pagina 42 van 63
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
42 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
** Note: The 4 gang push-button allow you to set the button orientation to either “horizontal (left/right)”
or “vertical (top/bottom)”. The settings for “Sending condition for long keypress” can vary between “...
upper/lower button” and ”... left/right button”.
Functional principle
■ Single-button function: Only one value each can be sent for short and long keypresses. The datapoint
type can be set separately for short and long keypresses.
■ Two-button function: Different values for the upper/left and lower/right buttons can be sent for both,
short and long keypresses.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 PB1 short: –
PB1/2 short: –
Switch, Forcible control, ...
Sending the value for the short button.
DPT depending on the parameter setting.
1 PB1 short: –
PB1/2 short: – Status for toggle
1 Bit Receive the status for the short button.
Only with the “toggle” function.
2 PB1 long: –
PB1/2 long: –
Switch, Forcible control, ...
Sending the value for the long button.
DPT depending on the parameter setting.
3 PB1 long: –
PB1/2 long: – Status for toggle
1 Bit Receive the status for the long button.
Only with the “toggle” function.
Table 26: Communication objects – Switch/send values short/long
