MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
40 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.4 Switch/send values short/long (with 2 objects)
Single-button function
Two-button function
With this function, 2 different values can be sent for the short and long button. The short and the long
button have different objects, whereby it is also possible to send out different datapoint types.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Action on short
keypress
■ switch
■ switch OFF
■ switch ON
■ toggle
■ send values
■ not active
Setting the function for the short
keypress.
“switch“ only for two-button
function.
“switch ON“ and “switch OFF“
only for single-button function.
Two-button function: If “Action short keypress“ → “Switch“
Value button 1/3 ■ OFF
■ ON
Setting the value to be sent.
Value button 2/4 ■ OFF
■ ON
Setting the value to be sent.
If “Action on short keypress“ → “Send values“
Datapoint type ■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
Value
Scene number
RGB value
HSV value
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for single-button function.
Value
button 1/2 (3/4)
Scene number
button 1/2 (3/4)
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for two-button function.
