4.3.3.4 Subfunction: Send values by state
Single-button function
This function allows a xed value to be sent according to the selected datapoint type when pressing or
releasing the button.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 2 Bit DPT 2.001 Forcible control
■ 1Byte DPT 5.001 Percent (0…100%)
■ 1Byte DPT 5.005 Decimal factor (0…255)
■ 1Byte DPT 17.001 Scene number
■ 2Byte DPT 7.600 Colour temperature (K)
■ 2Byte DPT 9.001 Temperature (°C)
■ 2Byte DPT 9.004 Brightness (Lux)
■ 3Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
Value for pressed
button
Scene number for
pressed button
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Value for released
button
Scene number for
released button
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Table 21: Settings – Send values – Subfunction: Send values by state
The value to be sent can be set according to the set datapoint type for pressing as well as for releasing the
key.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 PB1: –
Forcible control, Percent value, ...
Sending the value.
DPT depending on the parameter setting.
Table 22: Communication objects – Send values – Subfunction: Send values by state
