31 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
** Note: The 4 gang push-button allow you to set the button orientation to either “horizontal (left/right)”
or “vertical (top/bottom)”. The settings for “Group long sends” and “Group extra long sends” can vary
between “... upper/lower button” or “... left/right button”.
Additional Object
When selecting “additional object”, another communication object appears. It is possible here to send
different values to two separate objects when pressing a button. For example, a dimming value in “%” can
be sent to a dimming actuator with the rst object and at the same time an “RGB value” to an LED
controller with the second object.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 PB1: –
PB1/2: – Switch, Scene ...
Switch function of the button(s).
DPT depending on the parameter setting.
2 PB1: (2. object) –
PB1/2: (2. object) –
Switch, Scene ...
Switch function of the button(s) on the second object.
DPT depending on the parameter setting.
2 PB1: Group long –
PB1/2: Group long –
Switch, Scene ...
Switch function with long keystroke.
DPT depending on the parameter setting.
4 PB1: Group extra long –
PB1/2: Group extra long –
Switch, Scene ...
Switch function with extra long keystroke.
DPT depending on the parameter setting.
Table 16: Communication objects – Send values – Subfunction: Send values
