Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.2.2 Subfunction: Switch
Single-button function
Here the button sends the respective xed set value (ON or OFF) when pressed.
Note: For details on the Innovative group control, see 4.3.2 Switch (General).
The following table shows the available communication objects:
No. Name/Object function Length Usage
0 PB1: – Switch 1 Bit Switch function.
2 PB1 Group long: – Switch 1 Bit Switch function for long keypress.
4 PB1 Group extra long: – Switch 1 Bit Switch function for extra long keypress.
Table 12: Communication objects – Single-button function Switch – Subfunction: Switch
4.3.2.3 Subfunction: Toggle
Single-button function
With this function, the button sends the inverted value in relation to the last received status value.
For this purpose, the status object “Status for toggle” is connected to the status of the actuator to be
controlled. If a “1” signal was received as the last value, the button sends a “0” command to the “toggle”
object the next time it is pressed.
Note: For details on the innovative group control, see 4.3.2 Switch (General).
The following table shows the available communication objects:
No. Name/Object function Length Usage
0 PB1: – Toggle 1 Bit Switch function of the button.
1 PB1: – Status for toggle 1 Bit Receiving the switching status of the actuator.
2 PB1 Group long: – Toggle 1 Bit Switch function for long keypress.
4 PB1 Group extra long: – Toggle 1 Bit Switch function for extra long keypress.
Table 13: Communication objects – Single-button function Switch – Subfunction: Toggle
