Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Threshold for
minimum brightness
(level 1)
0 … 1000 Lux
[50 Lux]
Setting from which value the brightness
level 1/5 is active.
Only if “Datapoint for dynamic
brightness“ → “Ambient Brightness“.
Threshold for
maximum brightness
(level 5)
0 … 1000 Lux
[500 Lux]
Table 36: Settings – LED basic setting
LED colour on button activation
This parameter species the colour of all status LEDs when a button is pressed if they are assigned a
double function by the setting “LED reacts to external/internal object and button press”. In this case, the
settings in the menu items LED 1 - 4 refer to the control via the object.
Global brightness for LEDs
The brightness of the LEDs can be set either statically or dynamically. If the brightness is to be adjusted
dynamically, it is controlled by a lux or percentage value, depending on how the system is congured. The
brightness is set in 5 brightness levels. If a lux value is used, the brightness thresholds are calculated
using the minimum and maximum brightness values.
If a percent value is used, the thresholds are xed as follows:
Level Lower Percent value Upper Percent value
1 0 % 20 %
2 21 % 40 %
3 41 % 60 %
4 61 % 80 %
5 81 % 100 %
Table 37: LED brightness thresholds if controlled via percent value
If no valid object value is available, the “Global brightness for “Day” is set to “level 3” and the “Global
brightness for “Night” to “level 1”.
Lock object for LEDs
Unlike the lock objects for the buttons, there is only one lock object for the LEDs, which affects all LEDs. If
the LED lock object is controlled with a logical “1”, all LEDs are locked and can therefore no longer be
controlled. LEDs that were previously controlled are switched-off. With a logical “0”, the lock is removed
and control is possible again. Previous switching states are restored.
Synchronization object for flashing LEDs
This parameter can be used to synchronise the flashing of the status LEDs on different push-buttons. One
push-button must be congured as “active as master” and all other buttons as “active as slave”. The
“master” sends a synchronisation signal at approx. 10-minute intervals, which the slave LEDs follow. This
ensures that every button with a status LED flashes at the same time.
