MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
30 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Group long sends ■ value for upper/left and lower/right
button
■ only value for upper/left button
■ only value for lower/right button
Setting, which button is to send
when the button is pressed long.
Only for two-button function.
** see note below table.
Group extra long
keypress
■ not active
■ active
Activation of the group for extra
long keypress.
Group extra long
sends
■ value for upper/left and lower/right
button
■ only value for upper/left button
■ only value for lower/right button
Setting, which button is to send
when the button is pressed long.
Only for two-button function.
** see note below table.
Time for long
keypress
basic setting
0,1 s - 30,0 s
Setting of an individual time from
when a long keystroke is detected.
Time for extra long
keypress
0,1 s - 30,0 s
[2,0 s]
Setting of an individual time from
when an extra long keypress is
detected.
“Special function“ → “additional object“
Datapoint type
(2. object)
■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only “RGB value“.
Value
button 1 (3) / 2 (4)
Scene number
button 1 (3) / 2 (4)
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for two-button function.
Value
Scene number
RGB value
HSV value
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for single-button function.
Table 15: Settings – Send values – Subfunction: Send values
Note: For details on the innovative group control, see 4.3.2 Switch (General).
