MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
29 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.3 Send values
4.3.3.1 Subfunction: Send values
Single-button function
Two-button function
With this function, different values of a datapoint type can be sent.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for “RGB value“.
Value button 1 (3)
Scene number
button 1 (3)
any value
according to set datapoint type.
Setting the value/scene number to
be sent.
Only for two-button function.
Value button 2 (4)
Scene number
button 2 (4)
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for two-button function.
Value
Scene number
RGB value
HSV value
any value
according to set datapoint type.
Setting the value to be sent for the
button.
Only for single-button function.
Special function ■ innovative group control
■ additional object
Selection of the special function.
“Special function“ → “innovative group control“
Group long keypress ■ not active
■ active
Activation of the group for long
keypress.
