Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
LED reacts to: external object
If the setting “LED reacts to:” → “external object” is selected, various datapoint types can be selected:
■ 1 Bit DPT 1.001 Switch: The LED behaves like the object. The states can be congured if “ON” and
“OFF”.
■ 1 Byte DPT 5.001 Percent (0...100 %): The value is specied here from which the LED switches to
“ON”. If the specied value is reached, the LED is switched on, and if the value is below the set value,
the LED is switched off.
■ 1 Byte DPT 5.001 Decimal factor (0...255): The values from 0 to 7 can be used to specify whether the
LED should light up and, if so, which colour it should be:
Table 40: Assignment of LED colour to decimal value
Day/Night
Each LED can assume different colours, brightnesses and behaviours for Day and Night mode. The
switchover is dependent on the “Day/Night” communication object.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
62 LED 1 – Switch, Percent value, Decimal value 1 Bit
1 Byte
Control of LED.
+1 next LED
Table 41: Communication objects – LED 1 - 4
Value Colour
0 Off (Black)
1 White
2 Red
3 Green
4 Blue
5 Yellow
6
Pink
7 Cyan
