MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
50 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
Threshold for minimum/maximum brightness
The dynamic brightness control of the LEDs can be based either on the measured values of a brightness
sensor or on percent values. The brightness of the LEDs is increased linearly based on the threshold values
for minimum and maximum brightness. As long as no object value has been received, the brightness of the
LEDs is set to level 3 during the day and to level 1 at night.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
70 LED – Lock object 1 Bit Locking all LEDs.
78 LED - Synchronise – Flashing status as
Master
1 Bit Sends the flashing status for synchronisation.
78 LED - Synchronise – Flashing status as
Slave
1 Bit Receives the flashing status for synchronisation.
79 Brightness – Input for dynamic
brightness
1 Byte
2 Byte
Input for dynamic brightness adjustment.
Table 38: Communication objects – LED basic setting
4.4.2 LED 1 - 4
Push Button Lite 55/63
Number of LEDs depending on device type
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
LED active ■ no
■ yes
Activation of the LED.
LED reacts to: ■ external object
■ internal object
■ button activation
■ external object and
button activation
■ internal object and
button activation
Setting in which way the “Status LED” is
controlled.
Selection of object
number
0 ... 79
[0]
Link to an internal object.
Only if “LED reacts to:“ → “internal Object”.
Datapoint type ■ 1 Bit DPT 1.001 Switch
■ 1 Byte DPT 5001
Percent (0...100%)
■ 1 Byte DPT 5.005
Decimal factor (0...255)
Datapoint type of the external object.
Only if “LED reacts to:“ → “external Object”
