MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
44 / 63
Technical Manual
Push Button Lite 55/63/Basic [BE-TALxxxx.x1]
State 09/2024 - Version 1.4
4.3.6 Blinds/Shutter
Single-button function
Two-button function
This function is used to control Shutter Actuators, which can be used to adjust and control shutter and
blinds.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(1/2) (3/4)
■ Up/Down
■ Down/Up
Setting the key assignment.
Only for two-button function.
Operating function ■ long=Up/Down /
short=Stop/Slats Open/Close
■ short=Up/Down /
long=Stop / Slats Open/Close
■ short=Up/Down/Stop
(MDT Single Object Control)
■ short=Up/Down/Stop /
Long=Central object
(MDT Single Object Control)
Setting the concept of how to operate
with long/short button.
Only for two-button function.
Operating function ■ long=move /
short=Stop / Slats Open/Close
■ short=move /
long=Stop / Slats Open/Close
Setting the operating concept.
Only for single-button function.
Time for long
keypress
basic setting
0,1 s - 30,0 s
Setting from when a long keypress is
detected.
Innovative group control (Only with setting “long=Up/Down/short=Stop/Slats Open/Close“
Group control extra
long
■ not active
■ active
Activation of the group for extra long
keypress.
Time for extra long
keypress
0,1 s - 30,0 s
[2,0 s]
Setting a time from when an extra long
keystroke is detected.
Table 30: Settings – Blinds/Shutter
Two communication objects are displayed for the “blinds/shutter” function: The object “Stop/Slats Open/
Close” and the object “Blinds/Shutter Up/Down “.
The moving object is used to move the blinds/shutters “Up” and “Down”.
The stop/step object has two functions: on the one hand, it stops the blinds/shutters from moving up or
down if they have not reached the end position, and on the other hand, it is used to adjust the slats.
