MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
40 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
LED reacts to: external object
With this selection, a communication object “LED X: Switch” is displayed. This object can then be
connected to any 1 Bit object. In this way, the LED can, for example, indicate the switching status of an
actuator that is independent of the button.
LED reacts to: internal object
With this selection, the object number to which the LED is to be linked is selected. For example, if the LED
is to switch when (with setting: button 1 to “Toggle”) the “Object 1 - Status for Toggle” has the value “1”,
the object number 1 must be entered. In this case, the status LED would be switched on with a logical “1”
and switched off with a logical “0”.
If the LED is linked to an object that does not have the size 1 Bit, the LED is switched off if the object has
the value “0” and switched on if the value of the object is “not 0”. For an object of the DPT 5.001 - percent,
this means that the LED is switched-off at 0% and switched-on at all other values.
LED reacts to: button activation
This selection causes the LED to react to the operation of the corresponding button. The action that the
LED should take when a button is pressed or released can be congured individually for both states using
the ‘LED display behaviour’.
Note: The flashing behaviour is only supported by devices with hardware R3.2 or later.
LED reacts to: external object and button activation
In this case, the LED reacts to both possibilities. First, a value must be received via the object. If the button
is then pressed, the state (colour) is inverted.
Example: Value when ‘ON’ = green (permanent). When the button is pressed, the LED turns red
(permanent). When the button is released, the previous state applies.
Note: After a bus voltage failure, a value must be received before the LED can react to a button being
operated.
The following table shows the available communication objects:
No. Name / Object function Length Usage
* 32/52/72/92 LED 1 – Switch 1 Bit Control of the LED. Only shown with
“LED reacts to: external object”.
Table 36: Communication objects – Switch object for LEDs
* Object numbers depend on the device version (number of buttons).
