MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
30 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.4 Switch/send value short/long (with 2 objects)
; Single-button function
; Two-button function
With this function, 2 different values can be sent for the short and long button. The short and the long
button have different objects, whereby it is also possible to send out different datapoint types.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Action on short/long
keypress
■ switch
■ OFF
■ ON
■ toggle
■ send value
■ not active
Setting the function for the
short/long button.
■ „Switch” only with two-
button function.
■ „OFF/ON“ only with single-
button function
Datapoint type ■ 2 Bit DPT 2.001 Switch Control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600
Colour temperature (Kelvin)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600
RGB Value 3x (0…255)
Only available when „Action on
short/long keypress“ is set to
„send values“.
Setting the datapoint type for the
value to be sent..
Left/Right button:
Value / Scene
number
any value according to set datapoint type Only with two-button function.
Setting the values to be sent for
the two buttons.
Value / Scene
number
any value according to set datapoint type Only for single-button function.
Setting the value to be sent for
the button.
Colour control ■ RGB
■ HSV
Selection of the colour system.
Only for „3Byte DPT…RGB“
Behaviour on long
keypress
■ do not send „short button“
■ send „short button“
Setting whether the value for the
short button should also be sent
with a long keypress.
Sending condition
for long keypress
■ left and right button may send
■ only left button may send
■ only right button may send
Only with two-button function.
Set the send condition for the
long button.
Time for long
keypress
Basic setting
0,1 s – 30,0 s
Setting of a time from when a
long keystroke is detected.
Table 21: Settings – Switch/Send values short/long (with 2 objects)
