22 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.2.3 Subfunction: Toggle
; Single-Button function
With this function, the button sends the respective inverted value in relation to the last received status
value.
For this purpose, the status object “Status for toggle” is connected to the status of the actuator to be
controlled. If a “1” signal was received as the last value, the button sends a “0” command to the “Toggle”
object the next time it is pressed
Note: For details on the Innovative group control, see 4.3.2 Switch (General)
The following table shows the available communication objects:
No. Name / Object function Length Usage
0 PB1: – Toggle 1 Bit Switch function of the button
1 PB1: – Status for Toggle 1 Bit Receive switching status from actuator.
2 PB1 Group long: – Toggle 1 Bit Switch function of the button with long keypress
4 PB1 Group extra long: – Toggle 1 Bit Switch function of the button with extra long
keypress
Table 13: Communication objects – Single-button function: Toggle
4.3.2.3 Subfunction: Send State
; Single-Button function
With this function, xed values can be sent for a pressed button (rising edge) and a released button (falling
edge).
In addition, it is possible to set a delay for the released button. This means that the value for the pressed
button is sent immediately, but the value for the released button is sent only after the respective set delay.
For example, a light can be switched on when the button is pressed, but the light remains on for a few
seconds after the button is released. This time is then left, for example, to leave a room without walking in
the dark.
The following table shows the available communication object:
No. Name / Object function Length Usage
0 PB1: – Send state 1 Bit Switch function of the button
Table 14: Communication objects – Single-button function: Send state
