Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.3.3 Subfunction: Send value by state
; Single-button function
This function allows a xed value to be sent according to the selected datapoint type when pressing or
releasing the button.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 2 Bit DPT 2.001 Switch Control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor
(0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600
Colour temperature (Kelvin)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600
RGB Value 3x (0…255)
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selecting the colour system
With „3 Byte DPT…RGB value“.
Value/Scene number
for pressed / released
button
any value according to set datapoint type Setting of the values to be sent.
Table 19: Settings – Send values - Subfunction: Send value by state
The value to be sent can be set according to the set datapoint type for pressing as well as for releasing the
key.
The following table shows the available settings:
No. Name / Object function Length Usage
0 PB1: –
Forcible control, Percent value…
Sending the value.
DPT depending on the parameter setting
Table 20: Communication objects – Send values - Subfunction: Send value by state
