MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
18 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3 Button functions
4.3.1 Identical parameter
4.3.1.1 Lock object
The lock object can be activated for grouped buttons as well as for single buttons. If the lock object is
active, a communication object is displayed for the respective button or button pair. Depending on the
device type, up to 8 lock objects can be activated.
If the disable object is assigned a logical “1”, the corresponding button is “locked” and can therefore no
longer be switched. A “0” cancels the lock.
The following table shows the associated communication objects:
No. Name / Object function Length Usage
9 T1:
T1/2: – Lock object
1 Bit Locks the button function
Table 9: Identical communication object – Lock object
4.3.1.2 Button/Object description
A text eld is available for each button or button pair for free labelling:
Figure 3: Identical parameter – Text eld: Button/Object description
A text with up to 30 characters can be stored for the eld.
The text entered in “Button/Object description” appears both in the menu behind the corresponding
functions and with the communication objects of the functions:
Figure 4: Button/Object description
