Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
Standard Settings – Logic
No. Name Object Function Length C R W T U
* 20/40/60/80 Logic 1: Input A 1 Bit
■ ■ ■ ■
* 21/41/61/81 Logic 1: Input B 1 Bit
■ ■ ■ ■
* 22/42/62/82 Logic 1: Output: Switch 1 Bit
■ ■ ■
* 22/42/62/82 Logic 1: Output: Value 2 Bit
■ ■ ■
* 22/42/62/82 Logic 1: Output: Value 1 Byte
■ ■ ■
* 22/42/62/82 Logic 1: Output: Scene 1 Byte
■ ■ ■
+ 3 next Logic
Table 2: Communication objects – Standard settings: Logic
* Logic objects always come after the buttons in the object list. This means that the object numbers are
dependent on the device version.
2 gang Push Button from object no. 20
4 gang Push Button from object no. 40
6 gang Push Button from object no. 60
8 gang Push Button from object no. 80
Standard Settings – Status LED
No. Name Object Function Length C R W T U
* 32/52/72/92 LED 1 Switch 1 Bit
■ ■ ■ ■
+ 1 next LED
* 34/56/78/100 LED 1 Priority Switch 1 Bit
■ ■ ■ ■
+ 1 next LED Priority
* 36/60/84/108 All LEDs Lock object 1 Bit
■ ■ ■ ■
Table 3: Communication objects – Standard settings: Status LED
* Objects for Status LEDs always come after the buttons in the object list. This means that the object
numbers are dependent on the device version.
2 gang Push Button from object no. 32
4 gang Push Button from object no. 52
6 gang Push Button from object no. 72
8 gang Push Button from object no. 92
