MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
23 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.3 Send values
4.3.3.1 Subfunction: Send values
; Single-button function
; Two-button function
With this function, different values of a datapoint type can be sent.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Switch Control
■ 1 Byte DPT 5.001 Percent
(0…100%)
■ 1 Byte DPT 5.005 Decimal factor
(0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600
Colour temperature (Kelvin)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600
RGB Value 3x (0…255)
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selecting the colour system
With „3 Byte DPT…RGB value“.
Left/Right button:
Value/Scene number
any value according to set datapoint
type
Only with two-button function.
Setting the values to be sent for the
two buttons.
Value/Scene number any value according to set datapoint
type
Only with single button function.
Setting the value to be sent for the
button
Special function ■ innovative group control
■ additional object
Selection of the possible special
function
Special function: Innovative group control
Group long keypress ■ not active
■ active
Activation of the group for long
keystroke.
Group long sends ■ value for left and right button
■ only value for left button
■ only value for right button
Only with two-button function.
Setting, which button is to send when
the button is pressed long.
