Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.6 Temperature (only Push Button Plus TS 55)
Using the internal temperature sensor, the current temperature of the room can be recorded and output to
the bus.
The following table shows all available settings:
ETS Text
Dynamic range
[Default value]
Comment
Temperature
measurement
■ not active
■ active
Activation of the temperature
measurement.
Sensor internal/
external
■ 100% internal
■ 90% internal / 10% external
■ 80% internal / 20% external
■ …
■ 10% internal / 90% external
Activation of an external sensor
and setting of the weighting
between internal and external
sensor.
Send measured value
cyclically
not active, 1 min – 4 h
[20 min]
Setting whether and at what
interval the measured value is to
be sent cyclically.
Send measured value
on change of …
not active, 0,1 °C – 5,0 °C
[0,2 °C]
Setting at which change the
measured value is to be sent.
Calibration value for
internal temperature
-50 … 50 x 0,1 K
[0]
Raise/lower the internal
temperature to correct the
measured temperature.
Temperature for upper
message value
not active
20 °C – 45 °C
Activation of a message when a
certain temperature is exceeded.
Temperature for lower
message value
not active
3 °C – 30 °C
Activation of a message when the
temperature falls below a certain
level.
Table 43: Settings – Temperature
An external sensor can be activated or deactivated via the weighting “Sensor internal/external”. If the
weighting is set to 100% internal, no external sensor is activated and no communication object appears
for the external sensor. With any other setting, an external sensor is activated and the associated object
appears. The “mixed” value is sent to the bus via the “Send measured value” object.
Note: As long as the external sensor does not receive a value via the object, only the internal sensor is
used! A “mixed” value (according to the set weighting) is always calculated and output when a new
external value is received.
External values outside the range “-9.9 ... +50 °C” are invalid. In this case, only the internal value is used.
