MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
20 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
ETS Text
Dynamic range
[Default value]
Comment
Group extra long sends ■ ON and OFF
■ only ON
■ only OFF
Only for two-button function, when
„Group long keypress“ and “Group
extra long keypress” are active.
Denes the sending behaviour when
an extra long keypress is active.
For single-button functions, the
sending behaviour is dened
according to the subfunction.
Time for long keypress Basic setting
0,1 s – 30,0 s
Setting from when a long keypress is
detected. Basic setting refers to the
time at menu "Button functions".
Time for extra long keypress 0,1 s – 30,0 s
[2,0 s]
Setting from when an extra long
keypress is detected
Table 10: Settings – Switch
With the “Innovative group control”, it is possible to send to up to three different group addresses by
touching/pressing a button for a longer time. The time for the long and the extra-long keystroke is set
individually.
■ Single-button function: The value dened in the sub-function is always sent for the long and the
extra-long group as well.
■ Two-button function: The transmission behaviour for the long and the extra-long group can be set
individually.
Note: All groups are always sent one after the other.
Example:
Time long key press: 2 s
Time extra long key press: 4 s
If the key is now pressed for at least 4 seconds, the rst value is transmitted immediately, after 2 seconds
the value for “group long” and after 4 seconds the value for “group extra long”.
.
