MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
36 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.7 Dimming
; Single-button function
; Two-button function
The dimming function can be used to control dimming actuators.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
■ brighter/darker
■ darker/brighter
Only with two-button function.
Setting the key assignment for the
brighter/darker function.
Time for long keypress Basic setting
0,1 s – 30,0 s
Setting of the time from when a long
keystroke is to be detected.
Table 29: Settings – Dimming
With the single-button function “dimming”, two communication objects appear for this button. Firstly, the
function for a short button action, the “Dimming On/Off” switch object, and secondly the function for a
long button action, the dimming object “Dimming relative”.
The two-button function “dimming” can be set either as brighter/darker or as darker/brighter. The
relationships are shown in the following table:
Function brighter/darker Function darker/brighter
Input Button left Button right Button left Button right
Dimming function brighter darker darker brighter
Switch function ON OFF OFF ON
Table 30: Two-button function – Dimming
With the single-button function “dimming”, the direction (brighter/darker) is reversed depending on the
communication object “Status for toggle”.
The dimming function is a start-stop dimming function, i.e. as soon as the dimming function becomes
active, a brighter or darker command is assigned to the input until it is released. After the command is
released, a stop telegram is sent which ends the dimming process.
The following table shows the available communication objects:
No. Name / Object function Length Usage
0 PB1:
PB1/2: – Dimming On/Off
1 Bit Switch command for the dimming function
1 PB1:
PB1/2: – Dimming relative
4 Bit Command for relative dimming
2 PB1: – Status for toggle 1 Bit Only for single button function.
Receiving the status with information about the
status of the actuator to be controlled
Table 31: Communication objects – Dimming
