MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
45 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.5.2 Submenu - Logic 1-4
A new submenu opens for each activated logic. The following settings are possible:
ETS Text
Dynamic range
[Default value]
Comment
Logic object A/B
(external)
■ not active
■ normally active, with preallocation “0”
■ inverted active, with preallocation “0”
■ normally active, with preallocation “1”
■ inverted active, with preallocation „1“
Activation of the external logic
objects.
The preallocation denes the
value of the external logic object
after a bus power return if no
value has yet been sent to the
communication object.
Internal input 1/2 ■ not active
■ button 1 - 2/4/6/8
Activating the buttons for the logic
function.
Button 1-2/4/6/8 ■ pressed = ON
■ pressed = OFF
Setting of the value that is sent
when the button is pressed.
Only shown if “Internal input” is
active for a button.
Button selection ■ not active
■ button 1 - 2/4/6/8
Selection of the button that sends.
Only with the setting “Send value
on button activation” in menu
“Logic basic setting”.
Table 41: Settings – Submenu: Logic 1-4
Up to two external logic objects can be activated for the logic operations “AND”/”OR”. The default setting
denes the value of the external logic object after a bus power return if no value has yet been sent to the
communication object. Up to two buttons can be dened as “internal inputs” and the respective value that
the button sends when pressed.
Note: The setting “Send value on button activation” is a special function. This can be used to send a
second value when a button is pressed - in addition to the normal switch function. The value is determined
under “Setting logic X” (previous chapter). Here, the button that is to send the value is selected via the
“Button selection” parameter.
Depending on the activated inputs, the following communication objects are available:
No. Name / Object function Length Usage
* 20/40/60/80 Logic 1 – Input A 1 Bit external input for the logic operation
* 21/41/61/81 Logic 1 – Input B 1 Bit external input for the logic operation
Table 42: Communication objects – Logic inputs
* Object numbers depend on the device version (number of buttons).
