MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
39 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.4.2 LED 1 - x
The respective LEDs (per button) can be set here. The number of congurable LEDs depends on the device
type.
The following table shows all available settings:
ETS Text
Dynamic range
[Default value]
Comment
LED x ■ not active
■ active
Activation of the LED.
(„x“ stands for the LED number)
LED reacts to ■ external object
■ internal object
■ button activation
■ external object and button activation
(as of HW R3.2)
Setting for how the LED is to be
controlled.
Selection of object
number
any object
(selection of object numbers depends on
button type)
Link to internal object.
Only with „LED reacts to: internal
object“.
LED display behaviour Note: ‘Flashing’ is only supported as of HW R3.2.
for value „ON“
for pressed button
■ OFF
■ red (permanent)
■ green (permanent)
■ red (flashing)
■ green (flashing)
LED display behaviour when object
value is ‘ON’ or when button is
pressed.
Info Text according to the
selection under ‘LED reacts to’.
for value „OFF“
for released button
■ OFF
■ red (permanent)
■ green (permanent)
■
■ red (flashing)
■ green (flashing)
LED display behaviour when object
value is ‘OFF’ or when button is
released.
Info Text according to the
selection under ‘LED reacts to’.
Object for priority ■ not active
■ active, if object LED priority value=1
■ active, if object LED priority value=0
Activation of the LED priority for the
individual LEDs.
Colour / Behaviour ■ OFF
■ red (permanent)
■ green (permanent)
■ red (flashing)
■ green (flashing)
Setting for colour and display
behaviour for an active LED priority.
‘Flashing’ is only supported as of
HW R3.2.
Table 35: Settings – LED 1 - x
