MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
21 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.2.1 Two-button function – Switch
; Two-button function
With the two-button function, the respective value (ON/OFF) can be assigned to the left and right button.
Thus, the left or right button sends the set, xed value.
Button assignment ON/OFF: The left button sends the value “ON”, the right button sends the value “OFF”.
Button assignment OFF/ON: The left button sends the value “OFF”, the right button sends the value “ON”.
Note: For details on the Innovative group control, see 4.3.2 Switch (General)
The following table shows the available communication objects:
No. Name / Object function Length Usage
0 PB1/2: – Switch 1 Bit Switch function of the buttons
2 PB1/2 Group long: – Switch 1 Bit Switch function of the buttons with long keypress
4
PB1/2 Group extra long: – Switch
1 Bit Switch function of the buttons with extra long
keypress
Table 11: Communication objects – Two-button function: Switch
4.3.2.2 Subfunction: Switch
; Single-Button function
Here the button sends the respective xed set value (ON or OFF) when pressed.
Note: For details on the Innovative group control, see 4.3.2 Switch (General)
The following table shows the associated communication objects:
No. Name / Object function Length Usage
0 PB1: – Switch 1 Bit Switch function of the button
2 PB1 Group long: – Switch 1 Bit Switch function of the button with long keypress
4 PB1 Group extra long: – Switch 1 Bit Switch function of the button with extra long
keypress
Table 12: Communication objects – Single-button function: Switch
