MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
24 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
ETS Text
Dynamic range
[Default value]
Comment
Group extra long
keypress
■ not active
■ active
Activation of the group for extra long
keypress.
Group extra long
sends
■ value for left and right button
■ only value for left button
■ only value for right button
Only with two-button function.
Setting, which button is to send when
the button is pressed extra long.
Time for long keypress Basic setting
0,1 s – 30,0 s
Setting of an individual time from
when a long keystroke is detected.
Time for extra long
keypress
0,1 s – 30,0 s
[2,0 s]
Setting an individual time from when
a extra long keystroke is detected.
Special function: Additional object
Datapoint type
(2. object)
■ 1 Bit DPT 1.001 Switch
■ 2 Bit DPT 2.001 Switch Control
■ 1 Byte DPT 5.001 Percent
(0…100%)
■ 1 Byte DPT 5.005 Decimal factor
(0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600
Colour temperature (Kelvin)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600
RGB Value 3x (0…255)
Setting the type of datapoint to be
sent.
Left/Right button:
Value/Scene number
any value according to set datapoint
type
Only with two-button function.
Setting the values to be sent to the
2nd object.
Value/Scene number any value according to set datapoint
type
Only with single button function.
Setting the value to be sent to the
2nd object.
Table 15: Settings – Send values - Subfunction: Send values
Note: For details on the Innovative group control, see 4.3.2 Switch (General)
When selecting “additional object”, another communication object appears. It is possible here to send
different values to two separate objects when pressing a button. For example, a dimming value in “%” can
be sent to a dimming actuator with the rst object and at the same time an “RGB value” to an LED
controller.
