44 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
There are 2 text elds available:
Figure 5: Text elds – Function/Object description + Additional text
Texts with up to 40 characters can be stored for both elds.
The text entered in “Function/Object description” appears both in the menu behind the corresponding
logic and with the communication objects of the logic:
Figure 6: Function/Object description
The “Additional text” is merely additional information to the logic. This is not visible anywhere else.
If a logic operation is fullled, a value or a scene can be sent according to the selected object type.
Only for the object type “Switch” can a sending condition or a sending lter be dened for the output. The
logic operation can, for example, send with every input telegram, only send when the output of the logic
operation changes, or a sending lter can be activated. In this case, only a “1” or a “0” is sent when the
output changes. If the setting is “not automatic”, no output value is sent, but it can be requested.
In addition, with the object type “Switch” the output can be inverted and thus a “0” can be made into a “1”
and a “1” into a “0”.
The table shows the available communication objects:
No. Name / Object function Length Usage
* 22/42/62/82 Logic 1 – Output: Switch,
Output: Value, Output: Scene
Output of the logic operation.
DPT according to parameter setting
Table 40: Communication objects – Logic output
* Object numbers depend on the device version (number of buttons).
