Je bekijkt pagina 26 van 51
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
26 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.3.2 Subfunction: Toggle values/scenes (up to 4 values)
; Single-button function
; Two-button function
This function can be used to switch between up to 4 different values of a datapoint type.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
■ next / previous
■ previous / next
Only with two-button function.
Setting in which direction to switch
when left/right button is pressed.
Number of values ■ 2
■ 3
■ 4
Setting between how many values
are to be switched.
Datapoint type ■ 2 Bit DPT 2.001 Switch Control
■ 1 Byte DPT 5.001 Percent
(0…100%)
■ 1 Byte DPT 5.005 Decimal factor
(0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600
Colour temperature (Kelvin)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600
RGB Value 3x (0…255)
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selecting the colour system
With „3 Byte DPT…RGB value“.
1.-4. Toggle value /
Toggle scene number
any value according to set datapoint
type
Setting the respective value for the
toggle value.
Time delay between
value/scene switchovers
no delay
1 s – 10 s
Setting a delay between sending
the toggle values.
Long keypress ■ not active
■ active
Activating a function with a long
keystroke.
Action: Left/Right
button
■ 1.-4. Toggle value
■ 4. Toggle value if last 1. Toggle
value, otherwise 1.. Toggle value
■ send “0”
■ “OFF” to second object
■ “ON” to second object
Only with two-button function and
when „long keypress“ is active.
Setting the action with long
keystroke.
Number of possible switching
values according to the selection
“Number of values”.
