MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
32 / 51
Technical Manual
Push Button 55 / Plus 55 / Plus TS 55 [BE-TA55xx(06).x2]
State 07/2025 - Version 1.3
4.3.5 Scene
; Single-button function
The scene function allows you to call up and save scenes that cover different trades. If the memory
function is activated, it can be executed by pressing and holding down a key.
The following gure shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Save scene ■ not active
■ active
Release of saving the scenes. The
saving is carried out by a long
keystroke.
Time for long keypress Basic setting
0,1 s – 30,0 s
[1,0 s]
Only visible if “Save scene” is active.
Setting the time for the long keypress
to save a scene.
Scene number 1 – 64
[1]
Setting the respective scene number.
Table 23: Settings – Scene
Functional principle: Call up and save scene
With a short keypress, the set scene is sent.
With a long keypress, the set scene is saved (if “Save scene” is active).
The following table shows all available settings:
No. Name / Object function Length Usage
2 PB1: – Scene 1 Byte Call up/saving of scenes
Table 24: Communication object – Scene
To call up a scene or save a new value for the scene, the corresponding code is sent to the associated
communication object for the scene:
Scene
No.
Call Save
Decimal Hexadecimal Decimal Hexadecimal
1 0 0x00 128 0x80
2 1 0x01 129 0x81
3 2 0x02 130 0x82
…. …. …. …. ….
64 63 0x3f 191 0xBF
Table 25: Codes for calling and saving of scenes
