Technical Manual
Blind Push Button Smart 55 BE-JTA5504.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
16
16
4.2.1 Time settings
The following table shows the possible settings:
ETS-Text
Dynamic range
[Default value]
Comment
System time mode
▪ Master
▪ Slave
▪ Slave (Master on failure)
Setting according to which operating
mode the time switch works.
Send system time
cyclically every
not active
1 min – 24 h
[1 h]
Only for operating mode "Master".
Defines the transmission intervals of
the time.
Send system time
cyclically on failure
every
not active
1 min – 24 h
[1 h]
Only for operating mode "Slave
(Master on failure)". Defines the
transmission intervals of the time.
Automatic changeover of
summertime
▪ not active
▪ active (Europe)
▪ active (individual)
Defines whether the clock should
automatically change between
summer and winter time.
Shift
▪ 1 h
▪ 2 h
Only shown for "active (individual)".
Setting the difference between
summer and winter time.
Table 7: Settings – Time
When operating as a "Master", the system time is actively sent from the unit to the bus.
When selected as a "Slave", the unit receives the system time from another unit on the bus, for
example via an MDT IP Interface/Router.
With the setting "Slave (Master on failure)", the unit is set as a slave. If the system time is not
received from the external timer within a certain time, the unit becomes the "Master" and sends the
current time cyclically to the bus.
Note! A time must be defined for the function. The time for cyclical transmission of the "Slave"
should be set the same as the time for cyclical transmission of the "Master".
The "Automatic changeover of summertime" can be done in two ways. With the setting "active
(Europe)" the changeover takes place automatically at the set times in spring and autumn. With the
setting "active (individual)", the times can be set by the user. When activated, the following table
appears and is then configured accordingly:
Figure 5: Setting – Changeover summertime individual
Furthermore, it can be set whether the time shift should be 1 hour or 2 hours.
The table shows the objects relevant for date and time:
Number
Name/Object Function
Length
Usage
38
Time
3 Byte
Sending/receiving the time
39
Date
3 Byte
Sending/receiving the date
40
Time / Date
8 Byte
Sending/receiving time and date
Table 8: Communication objects – Time/Date
