Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.4 Status LED
Depending on the device and its conguration, up to 4 status LEDs can be congured. One LED can be
congured for each function, which is then labelled with LED 1 - 4 in the parameters.
4.4.1 LED basic setting
The LED basic settings affect all active status LEDs.
The following table shows all available settings:
ETS Text
Dynamic range
[Default value]
Comment
LED colour on button
activation, only with
setting “Object and
button activation”
[off], red, green, yellow, blue, pink, cyan,
white
Setting the colour.
The parameter only works if the “...
object and button activation”
parameter is selected in the relevant
LED menu under “LED reacts to”.
Lock object for LEDs ■ not active
■ active
Activates a lock object which can lock
(switch-off) all LEDs.
Behaviour of LEDs on
bus power return
■ do not request LED objects
■ request LED objects
Setting whether the objects are
requested after a reset.
Works only when “LED reacts for:“ →
“external Object“.
Synchronization
object for flashing
LEDs
■ not active
■ active as master
■ active as slave
This synchronises the flashing of
several buttons on different devices.
Global brightness for
LEDs “Day”
■ not active
■ level 1 - 5
■ dynamic
[level 3]
Setting the brightness of the LEDs if the
system is in day mode.
Global brightness for
LEDs “Night”
■ not active
■ level 1 - 5
■ dynamic
[level 1]
Setting the brightness of the LEDs if the
system is in night mode.
Only if “Global brightness ...“ → “dynamic“.
Datapoint type for
dynamic brightness
■ 2 Byte DPT 9.004 Ambient
Brightness (Lux)
■ 1 Byte DPT 5.001 Percent (0…100%)
Setting the DPT for brightness control.
