MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
45 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.3.7 Dimming
; Single-button function
; Two-button function
The dimming function can be used to control Dimming Actuators.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(1/2) (3/4)
■ brighter/darker
■ darker/brighter
Setting the key assignment.
Only for two-button function.
Time long keypress basic setting
0,1 s - 30,0 s
Setting of the time from when a long
keystroke is to be detected.
Table 34: Settings – Dimming
Two communication objects appear for this button. Firstly, the function for a short button action, the
“Dimming On/Off” switch object, and secondly the function for a long button action, the dimming object
“Dimming relative”. The dimming function is a start-stop dimming function, i.e. as soon as the dimming
function becomes active, a brighter or darker command is assigned to the input until it is released. After
the command is released, a stop telegram is sent which ends the dimming process.
Dimming as a Two-button function
The two-button function “dimming” can be set either as “brighter/darker” or as “darker/brighter”. The
relationships are shown in the following table:
Function: brighter/darker Function: darker/brighter
Input Button 1 Button 2 Button 1 Button 2
Dimming function brighter darker darker brighter
Switch function ON OFF OFF ON
Table 35: Two-button function – Dimming
Dimming as a Single-button function
With this function, the direction of dimming (brighter or darker) is reversed depending on the
communication object “Status for toggle”.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 PB1:
PB1/2: – Dimming On/Off
1 Bit Switch command for the dimming function.
1 PB1:
PB1/2: – Dimming relative
4 Bit Command for relative dimming.
2 PB1: – Status for toggle 1 Bit Receiving the status with information about the
status of the actuator to be controlled.
Only for single button function.
Table 36: Communication objects – Dimming
