Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Time for long keypress basic setting
0,1 s - 30,0 s
Setting from when a long keypress is detected.
Basic setting refers to the time at menu “Button
functions”.
Time for extra long
keypress
0,1 s - 30,0 s
[2,0 s]
Setting from when an extra long keypress is
detected.
Table 11: Settings – Switch
Innovative group control
With this function, it is possible to send to up to three different group addresses by pressing a button for a
longer time. The time for the long and the extra-long keystroke is set individually.
■ Two-button function: The sending behaviour for the long and the extra-long group can be set
individually.
■ Single-button function: The value dened in the sub-function is always sent for the long and the
extra-long group.
Notes: All groups are always sent one after the other.
Example:
Time for long keypress: 2 s Time for extra long keypress: 4 s
If the key is now pressed for at least 4 seconds, the rst value is transmitted immediately, after 2 seconds
the value for “group long” and after 4 seconds the value for “group extra long”.
4.3.2.1 Switching with two-button function
Two-button function
With the two-button function, the value (ON/OFF) can be assigned to the upper/left and lower/right button.
Thus, the upper/left or lower/right button sends the set, xed value.
■ Button assignment ON/OFF: The upper/left button sends the value “ON”, the lower/right button sends
the value “OFF”.
■ Button assignment OFF/ON: The upper/left button sends the value “OFF”, the lower/right button sends
the value “ON”.
Note: For details on the Innovative group control, see 4.3.2 Switch (General).
The following table shows the available communication objects:
No. Name/Object function Length Usage
0 PB1/2: – Switch 1 Bit Switch function.
2 PB1/2 Group long: – Switch 1 Bit Switch function for long keypress.
4 PB1/2 Group extra long: – Switch 1 Bit Switch function for extra long keypress.
Table 12: Communication objects – Two-button function: Switch
