Je bekijkt pagina 16 van 62
MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
16 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
Standard Settings – Logic
No. Name Object Function Length C R W T U
50 Logic 1 Input A 1 Bit
■ ■ ■ ■
51 Logic 1 Input B 1 Bit
■ ■ ■ ■
52 Logic 1 Output: Switch 1 Bit
■ ■ ■
52 Logic 1 Output: Value 2 Bit
■ ■ ■
52 Logic 1 Output: Value 1 Byte
■ ■ ■
52 Logic 1 Output: Scene 1 Byte
■ ■ ■
+ 3 Next Logic
Table 3: Communication objects – Standard settings: Logic
Standard Settings – Status LED
No. Name Object Function Length C R W T U
62 LED 1 Switch/Percent value/Decimal value 1 Bit
1 Byte
■ ■ ■ ■
+ 1 Next LED
66 LED 1 Priority Switch 1 Bit
■ ■ ■ ■
+ 1 Next LED priority
70 LED Lock object 1 Bit
■ ■ ■ ■
78 LED - Synchronise Flashing status as master 1 Bit
■ ■
78 LED - Synchronise Flashing status as slave 1 Bit
■ ■
79 Brightness Input for dynamic brightness 1 Byte
2 Byte
■ ■ ■ ■
Table 4: Communication objects – Standard settings: Status LED
Standard Settings – Temperature
No. Name Object Function Length C R W T U
73 Temperature Send measured value 2 Byte
■ ■ ■
74 Temperature External sensor - Input 2 Byte
■ ■
75 Temperature Maximum value exceeded 1 Bit
■ ■ ■
76 Temperature Minimum value fallen below 1 Bit
■ ■ ■
Table 5: Communication objects – Standard settings: Temperature
