Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Behaviour on long
keypress
■ do not send “short button”
■ send “short button”
Setting whether the value for the
short button should also be sent .
Action on long
keypress
■ switch
■ switch OFF
■ switch ON
■ toggle
■ send values
■ not active
Setting the function for the long
button.
“switch“ only for two-button
function.
“switch ON“ and “switch OFF“
only for single-button function.
Sending condition for
long keypress
■ upper/left and lower/right button may
send
■ only upper/left button may send
■ only lower/right button may send
Set the send condition for the long
button.
Only for two-button function.
** see note below table.
Two-button function: If “Action on long keypress“ → “switch“
Value button 1/3 ■ OFF
■ ON
Setting the value to be sent.
Value button 2/4 ■ OFF
■ ON
Setting the value to be sent.
If “Action on long keypress“ → “Send values“
Datapoint type ■ 2 Bit DPT 2.001 Forcible control
■ 1 Byte DPT 5.001 Percent (0…100%)
■ 1 Byte DPT 5.005 Decimal factor (0…255)
■ 1 Byte DPT 17.001 Scene number
■ 2 Byte DPT 7.600 Colour temperature (K)
■ 2 Byte DPT 9.001 Temperature (°C)
■ 2 Byte DPT 9.004 Brightness (Lux)
■ 3 Byte DPT 232.600 RGB value
Setting the type of datapoint to be
sent.
Colour control ■ RGB
■ HSV
Selection of colour system.
Only for DPT “RGB value“.
Value
Scene number
RGB value
HSV value
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for single-button function.
Value
Button 1/2 (3/4)
Scene number
Button 1/2 (3/4)
any value
according to set datapoint type
Setting the value/scene number to
be sent.
Only for two-button function.
Time for long
keypress
basic setting
0,1 s - 30,0 s
Setting of a time from when a long
keypress is detected.
Table 26: Settings – Switch/send values short/long
