MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
33 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.3.3.3 Subfunction: Shift value
Two-button function
The function “shift value” can be used to move a value up or down within the set limits.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Buttons 1/2 (3/4)
shift the values
■ downwards/upwards
■ upwards/downwards
Setting the direction of the value shift.
Datapoint type ■ 1 Byte DPT 5.001 Percent
(0...100%)
■ 1 Byte DPT 5.005 Decimal factor
(0...255)
Select the datapoint type for the value
shift.
“Datapoint type” → “1 Byte DPT 5.001 Percent (0...100%)”
Lower limit
0 - 100 %
[0 %]
Setting the lower limit value.
Upper limit 0 - 100 %
[100 %]
Setting the upper limit.
Step width 1 - 100 %
[10 %]
Setting the step size.
“Datapoint type” → “1 Byte DPT 5.005 Decimal factor (0...255)”
Lower limit 0 ... 255
[0]
Setting the lower limit value.
Upper limit 0 ... 255
[255]
Setting the upper limit.
Step width 1 ... 255
[10]
Setting the step size.
Repeated sending
with pressed button
■ not active
■ active
Activating the repeat send function while
holding down the button.
Repetition time 200 ms - 3 s
[1 s]
Repetition time between two telegrams
when the button is pressed.
Table 20: Settings – Send values – Subfunction: Shift value
Functional principle
The function moves the set datapoint type within the set limits. When the “downwards” button is pressed,
the set step size is subtracted from the last value and sent, and when the “upward” button is pressed, the
set step size is added to the last value and sent.
