MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
23 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.3.2 Switch (General)
Single-button function
Two-button function
The following gure shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(1/2) (3/4)
■ ON / OFF
■ OFF / ON
Denes the sending behaviour of the buttons.
Only for two-button function.
Subfunction ■ switch
■ toggle
■ send status
Denes the subfunction and displays further
parameters if required.
Only for single-button function.
Value for pressed
button
■ OFF
■ ON
Denes the sending behaviour of the button.
Only if “Subfunction“ → “switch“.
Only if “Subfunction” → “send status”
Value for pressed
button
■ OFF
■ ON
Denes the sending behaviour of the button.
Value for released
button
■ OFF
■ ON
Denes the sending behaviour of the button.
Delay for released
button
■ not active
■ active
Setting whether to send with a delay.
Time delay 1 s - 60 min
[1 s]
Denes a delay of the telegram to be sent.
Visible when “Delay for released button” is active.
Innovative group control
Group long keypress ■ not active
■ active
Activation of the group for long keypress.
Group long sends ■ ON and OFF
■ only ON
■ only OFF
Denes the sending behaviour when a long
keypress is active.
Only for two-button function and when “Group
long keypress“ is active.
For single-button functions, the sending
behaviour is dened according to the subfunction.
Group extra long
keypress
■ not active
■ active
Activation of the group for extra long keypress.
Group extra long
sends
■ ON and OFF
■ only ON
■ only OFF
Denes the sending behaviour
Only for two-button function, when “Group long
keypress“ and “Group extra long keypress” are
active.
For single-button functions, the sending
behaviour is dened according to the subfunction.
