MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
58 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.6 Temperature
; Glass Push Button II Lite with temperature sensor
Using the internal temperature sensor, the current temperature of the room can be recorded and output to
the bus.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Temperature
measurement
■ not active
■ active
Activation of the temperature
measurement.
Sensor
internal/external
■ 100 % internal
■ 10 % external / 90 % internal
■ 20 % external / 80 % internal
:
■ 100 % external
Activation of an external sensor and
setting of the weighting between internal
and external sensor.
Send measured value
cyclically
not active, 1 min - 4 h
[5 min]
Setting whether and at what interval the
measured value is to be sent cyclically.
Send measurement
value on change of
not active, 0,1 °C - 5,0 °C
[0,2 °C]
Setting at which change the measured
value is to be sent.
Adjustment value for
internal temperature
-50 … 50 x 0,1 K
[0]
Raise/lower the internal temperature to
correct the measured temperature.
Temperature for
upper message value
not active
20 °C - 45 °C
Activation of a message when a certain
temperature is exceeded.
Temperature for lower
message value
not active
3 °C - 30 °C
Activation of a message when the
temperature falls below a certain level.
Table 52: Settings – Temperature
Sensor internal/external
An external sensor can be activated or deactivated via the parameter “Sensor internal/external”. If the
weighting is set to 100% internal, no external sensor is activated and no communication object appears
for the external sensor. With any other setting, an external sensor is activated and the associated object
appears. The “mixed” value is sent to the bus via the “Temperature – Send measured value” object.
Note: As long as the external sensor does not receive a value via the object, only the internal sensor is
used! A “mixed” value (according to the set weighting) is always calculated and output when a new
external value is received.
External values outside the range “-9.9 ... +50 °C” are invalid. In this case, only the internal value is used.
Send measured value cyclically
The setting can be used to set the intervals at which the sensor sends its current temperature value. The
cyclical transmission function can be activated or deactivated independently of the setting “Send
measured value on change of”. Measured values are also sent if the sensor has not detected a change. If
both parameters are deactivated, a value is never sent.
