Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
ON, if greater than 0 - 99 %
[50 %]
Denes the value at which the LED switches
on.
Only if “Datapoint type“ → "Percent“.
Brightness for
“Day” (global)
xed value
(cannot be changed here)
Brightness of the LED for day/night.
Can be set globally in “LED basic setting” →
“Global brightness for LEDs”.
Brightness for
“Night” (global)
LED display behaviour
Colour for “Day”
(value ON)
off, red, green, yellow, blue,
pink, cyan, [white]
Colour if object value “ON” or the button
pressed in day mode.
Colour for “Day”
(value OFF)
[off], red, green, yellow, blue,
pink, cyan, white
Colour if object value “OFF” or the button is
released in “Day” mode.
Behaviour for “Day”
(value ON)
■ permanent
■ flashing
Setting the LED behaviour for “DAY” if the
LED has the object value “ON” or the button
is pressed.
Colour for “Night”
(value ON)
off, red, green, yellow, blue,
pink, cyan, [white]
Colour if object value “ON” or the button
pressed in “Night” mode.
Colour for “Night”
(value OFF)
[off], red, green, yellow, blue,
pink, cyan, white
Colour if object value “OFF” or the button is
released in “Night” mode.
Behaviour for
“Night” (value ON)
■ permanent
■ flashing
Setting the LED behaviour for “Night” if the
LED has the object value “ON” or the button
is pressed.
Table 42: Settings – LED 1 - 4
Control of the LED
Each LED can either respond to any external object, such as the status of an actuator, or an internal object
or on button press.
Each LED can also react to an “external/internal object and button press”. If this setting is selected, the
settings in the LED 1 - 4 menu refer to the control of the LED via the object. In this case, the colour of the
LEDs when the button is pressed is set globally for all LEDs. (see chapter 4.4.1 LED basic setting). The
colour for the keypress is of primary importance.
LED reacts to: internal object
If this setting is selected, an internal object number can be selected to which the LED is linked. If the LED
is to switch if, for example, (if button 1 is set to toggle) the “Object 1 – Status for toggle” has the value 1,
then object number 1 must be entered. In this case, the status LED would be switched on if the object has
a “1” and switched off if the object has a “0”. If the LED is linked to an object that does not have the size 1
Bit, the LED is switched off if the object has the value “0” and switched on if the value of the object is
unequal to “0”. For an object with the datapoint type ‘percent value’, this would mean that the LED is
switched off at 0% and on for every other value.
