MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt.de
22 / 63
Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.3 Button functions
4.3.1 Identical parameter
4.3.1.1 Lock object
The lock object can be activated for grouped buttons (e.g. 1/2) as well as for single buttons (e.g. button 1
or button 2). If the lock object is active, a communication object for the button or button pair is displayed.
Up to four lock objects can be activated on a device with four button functions. If the lock object receives a
“1”, the corresponding button function is “locked” and can no longer react to activation. A “0” cancels the
lock.
The following table shows the associated communication object:
No. Name/Object function Length Usage
9 PB1: –
PB1/2: – Lock object
1 Bit Locks the corresponding button or button pair.
Table 10: Communication object – Lock object
4.3.1.2 Button/Object description
A text eld is available for each button or button pair for free labelling:
Button/Object description
Example - function
Figure 4: Identical parameter – Text eld
A text with up to 30 characters can be stored for the eld.
The text entered in “Button/Object description” appears both in the menu behind the corresponding
functions and with the communication objects of the functions:
Button/Object description
Communication objects
PB1/2: Example - function ...
|1 PB1/2: Example - function
|6 PB1: Example - function
Figure 5: Identical parameter – Text for Button/Object description
