Technical Manual
Glass Push Button II Lite [BE-GTLxxx.x1]
State 09/2024 - Version 1.4
4.2 Button functions – General
In the “Button functions” menu, the single buttons can be activated/deactivated and grouped.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button orientation ■ vertical (top/bottom)
■ horizontal (left/right)
Setting the button orientation/
assignment.
Only available for BE-GTL4xx.01 .
Buttons 1/2
(left top/bottom)
Buttons 3/4
(right top/bottom)
■ not active
■ single-button function
(2 functions, top/bottom)
■ single-button function
(1 function, top/bottom together)
■ two-button function
Setting the functions for the pair of
buttons.
If “Button orientation“ → “vertical (top/
bottom)“.
Buttons 1/2
(top left/right)
Buttons 3/4
(bottom left/right)
■ not active
■ single-button function
■ two-button function
Setting the functions for the pair of
buttons.
If “Button orientation“ → “horizontal
(left/right)“.
Slap/Cleaning
function
■ not active
■ active
Activates the slap/cleaning function.
Reaction time on
keypress
■ fast
■ medium
■ slow
Setting the reaction time or debounce
time for the buttons.
Time for long keypress
(Basic setting)
0,1 - 30 s
[0,4 s]
Setting from when a long keypress is
detected.
Table 9: Settings – Button functions
Button orientation (only BE-GTL4xx.01)
With the 4 gang buttons, you can choose whether the rocker is aligned horizontally (side by side) or
vertically (one above the other) for the two-button function.
For single-button functions, the orientation changes the sequence. Button 1 is always at the top left,
button 2 would be at the bottom left if the buttons were vertical, but at the top right if they were horizontal.
Buttons 3 and 4 are aligned accordingly.
Note: The assignment of the status LEDs automatically adapts to the orientation. LED 1 is always assigned
to button 1, LED 2 is assigned to button 2, etc.
