Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
80
80
Normal presentation
The dimming function can be presented with 3 freely selectable symbols and freely selectable
colours. The push-button evaluates the information of the "Object 3 - Status of dimming value for
display".
In addition, the current status can be displayed as text under the symbol.
Special presentation
Alternatively, a special symbol or a value can be displayed as text here. The information from "Object
3 - Status for display" is also evaluated here.
The following settings are available for this:
ETS-Text
Dynamic range
[Default value]
Comment
Special presentation
▪ bar symbol
▪ bar symbol with fan
▪ value as text (0 - 100%)
▪ value as text (0 - 255)
With the "bar symbol" settings, the
symbol is presented and the bar is filled
according to the current status.
With the settings "value as text", the
text is shown large on the display.
Figure 42: Special presentation – Dimming
