The following table shows the available settings:
ETS-Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
▪ next / previous
▪ previous / next
Only for two-button function.
Setting in which direction to
switch when the left/right
button is pressed.
Number of values
▪ 2
▪ 3
▪ 4
Setting between how many
values are to be switched.
Datapoint type
▪ 2 Bit DPT 2.001 Switch Control
▪ 1 Byte DPT 5.001 Percent
(0…100%)
▪ 1 Byte DPT 5.005
Decimal factor (0…255)
▪ 1 Byte DPT 17.001 Scene number
▪ 2 Byte DPT 7.600
Colour Temperature (Kelvin)
▪ 2 Byte DPT 9.001 Temperature (°C)
▪ 2 Byte DPT 9.004 Brightness (Lux)
▪ 3 Byte DPT 232.600
RGB Value 3x(0…255)
Setting the type of datapoint to
be sent.
1.-4. Toggle value
any value according to set datapoint type
Setting the respective value for
the toggle value.
Time delay between
value switchovers
no delay
1 s – 10 s
Setting a delay between
sending the toggle values.
Long keypress
▪ not active
▪ active
Activating a function with a long
keystroke.
Action on left/right
button
▪ 1.-4. Toggle value
▪ 4. Toggle value if last 1. Toggle
value, otherwise 1.
.
Toggle value
▪ Send “0”
▪ “OFF” to second object
▪ “ON” to second object
Only for two-button function!
Setting the action with long
keystroke.
Number of possible switching
values according to the
selection "Number of values".
Action on long
keypress
▪ 1.-4. Toggle value
▪ 4. Toggle value if last 1. Toggle
value, otherwise 1.
.
Toggle value
▪ Send “0”
▪ “OFF” to second object
▪ “ON” to second object
Only for single-button
function.
Setting the action with long
keystroke.
Number of possible switching
values according to the
selection "Number of values"
Time for long
keypress
Basic setting
0,1 s – 30 s
Setting of a time from when a
long keystroke is detected.
Switching type
▪ Limit stop (after the last value,
this is repeated)
▪ Overrun (after the last value, the
first value is sent again)
Only for two-button function.
Setting what should happen
when the last switching value is
reached.
Table 33: Settings – Send Values - Subfunction: Toggle values/scenes (up to 4 values)
