Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
31
31
Standby display
Incoming message during operation
No Standby
▪ No message is displayed but saved
Table 17: Behaviour of the device to an incoming message during operation
Standby display
Incoming message while Standby + Display brightness „Off“ via
brightness sensor
No Standby
▪ No message is displayed but saved
Standby in upper
keypad
▪ Brings display back to life (dark background lighting)
▪ After the " time until Standby " has expired, the backlight is switched
off again.
▪ Otherwise as in Standby
Standby over full
screen
▪ Brings display back to life (dark background lighting)
▪ After the " time until Standby " has expired, the backlight is switched
off again.
▪ Otherwise as in Standby
Display off
▪ Like in Standby
Display off and
orientation-LED on
▪ Brings display back to life (dark background lighting)
▪ After the " time until Standby " has expired, the backlight is switched
off again.
▪ Otherwise as in Standby
Table 18: Behaviour on arrival of a message in Standby with operation disabled
The following table shows the available communication objects:
Number
Name/Object Function
Length
Usage
142
Message 1 (highest priority) – Input
1 Bit
Triggering a message
143
Message 2 – Input
1 Bit
Triggering a message
144
Message 3 – Input
1 Bit
Triggering a message
145
Message 4 – Input
1 Bit
Triggering a message
146
Message 5 (lowest priority) – Input
14 Byte
Triggering a message. Send any
message text
Table 19: Communication objects – Messages
