Je bekijkt pagina 17 van 99
Technical Manual
Glass Push-button II Smart & Push-button Smart 86 [Series .02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
17
17
Behaviour after bus power return
Status for toggle
▪ no request
▪ request
Setting whether the values/objects are
to be automatically requested when
the bus voltage returns.
Day/Night object
▪ no request
▪ request
Date/Time
▪ no request
▪ request
Menu language
▪ German
▪ English
▪ French
▪ Spanish
Setting the language for the menus.
Value Day/Night
▪ Day = 1 / Night = 0
▪ Night = 1 / Day = 0
Sets the polarity for the Day/Night
object.
Table 6: General settings
Startup time
This time defines when the unit "boots up" after a restart (reset, reprogramming, bus voltage
recovery). This can be important if - example 1 - a bus reset is carried out. If there are many units on
a line, all units would start at the same time and load the bus. With a variable time, the units can thus
start differently.
Example 2: If “Time/Date”, “Status for toggle” or “Day/Night” object are queried, it makes sense that
the units responsible for them start up first, this unit only a little later. This ensures that all values are
available and correct.
„In operation“
"In operation" is used to show on the bus that the unit is "alive". If activated, an ON telegram is sent
cyclically.
Value for Day/Night:
Here the polarity for “Day/Night” is defined. Regardless of this polarity, the device always starts in
“Day”-mode after reprogramming.
Menu language
The set language refers to the "Programming mode" menu (accessible by simultaneously touching
the hidden sensor surfaces on the bottom right and left).
The object " Button operation" is permanently displayed. A "1" is sent via this object when any
button is pressed. If buttons are pressed at short intervals, the next telegram is sent at the earliest
after a fixed delay of 30 seconds.
The table shows the general communication objects:
Number
Name/Object Function
Length
Usage
133
Day/Night – Night = 1 / Day = 0
Day = 1 / Night = 0
1 Bit
Input of the value, whether "Day" or
"Night"
139
Time – Receive current value
3 Byte
Receiving the time
140
Date – Receive current value
3 Byte
Receiving the date
141
Time / Date–
Receive current values
8 Byte
Receiving time and date via a common
object
153
In operation – Output
1 Bit
Sending a cyclic "In operation" telegram
154
Button operation – Output
1 Bit
Sending a "1" when a button is pressed
Table 7: General communication objects
