8
Dolphin Explorer Classic 9 / Top 9 | User Instructions
4. Reassembling the filter elements
Insert the locating tabs at the bottom of the filter element into their grooves on the base frame
then close the “S” clip.
Reinstall the base frames with filters according
to the diagram.
CAUTION
Do not force the filters into place.
6.2. Dismantling and cleaning the impeller
CAUTION
Unplug the power supply before
cleaning.
Dismantle the impeller cover and clean around the
impeller housing, then reassemble.
(Use Phillips head screwdriver).
Locating tab
Locating tab groove
“S” clip
Octagonal
end
fitting
Grooved
end
fitting
8151620_Expolorer_all languages.indd 8 6/03/13 5:26 PM
