10
2. Attach the antenna coaxial cables to the top row
of connectors. These are marked ‘mobile’. Note the
order of the cables. These must be connected as
shown above for the best performance.
IMPORTANT - To prevent damage take
care to ensure the centre pins are
aligned before attaching the connector.
!
!
1. Position Router Bracket and mark hole positions.
Depending on material, drill a pilot hole or use a
bradawl. Mount the Router Bracket to the surface
using the 4 x No.6 Screws provided.
Note: Make sure the ‘Maxview Logo’ is
horizontal and in the correct orientation.
IMPORTANT - Ensure the router is not mounted
too close to other electrical devices, as this may
prevent it from working or negatively impact
performance.
Router Installation
!
3. Attach the Wi-Fi antennas to the bottom
connectors. These are marked ‘Wi-FI’. These should be
positioned so they are vertical.
5. Connect the 12V power lead or the 230V PSU
(available to order separately) and route the lead to
your power source.
4. Place the router into the mounting bracket.
The router can be removed from the bracket at any
time to change the SIM card as required.
The optimum positioning for the Wi-Fi antennas on
the Roam 5G Router is pointing directly upwards.
However, the unit can be fitted with the antenna at a
45° or 90° angle, or pointing downwards or forwards.
This may have a small detrimental effect on the
signal strength, which will become more significant
at greater distances from the router. However, for
leisure vehicle applications, this will likely only cause
a negligible drop in performance.
6. The installation is now complete. You may
wish to tidy up cable routing to suit your installation.
